Trane UHMB060ACV3VB User Manual

18-CD30D1-12 35
Installer’s Guide
DRIP LEG
DRIP LEG
W
AUTOMATIC GAS VALVE
WITH MANUAL SHUT-OFF
DRIP
LEG
DRIP
LEG
HORIZONTAL FURNACE GAS PIPING MAY BE FROM EITHER SIDE
(TYPICAL UPFLOW FURNACE IN HORIZONTAL CONFIGURATION SHOWN)
AUTOMATIC GAS VALVE
WITH MANUAL SHUT-OFF
THE DOWNFLOW (VERTICAL) MAY BE INSTALLED LEFT OR RIGHT SIDE GAS PIPING
Q
UPFLOW MAY BE LEFT OR RIGHT HAND GAS PIPING
AUTOMATIC GAS VALVE
WITH MANUAL SHUT-OFF
)
AUTOMATIC GAS VALVE
WITH MANUAL SHUT-OFF
DRIP
LEG
DRIP
LEG
DRIP
LEG
DRIP
LEG
IMPORTANT:
A sediment trap
must be installed
in the gas line be-
fore the furnace
gas valve. The sed-
iment trap must be
located as close to
the furnace cabinet
as practical.
IMPORTANT:
A sediment trap
must be installed
in the gas line be-
fore the furnace
gas valve. The sed-
iment trap must be
located as close to
the furnace cabinet
as practical.
IMPORTANT:
A sediment trap
must be installed
in the gas line be-
fore the furnace
gas valve. The sed-
iment trap must be
located as close to
the furnace cabinet
as practical.

Trane UHMB060ACV3VB Specifications

General

Brand	Trane
Model	UHMB060ACV3VB
Category	Furnace
Language	English
