Trane UniTrane - Zone Sensors

UNT-IOM-6 105
Terminal Unit
Control (TUC)
Sequence 1 Sequence 2 Sequence 3
Sequence 1 Sequence 2 Sequence 3
1 2 3 4 1 2 3 4 1 2 3 4


5 6 7 5 6 7 5 6 7
Table 42. Operating Control Mode LED Sequences and Codes
Sequence 1 Sequence 2 Sequence 3
1 2 3 4 1 2 3 4 1 2 3 4 Code Control Definition
Mode
 0 Stop Diagnostic, user switch,
Tracer
®
command or interlock
has stopped the unit
  2 Purge Incorrect entering water temp.
The TUC cannot meet the
demand. There is no other
capacity available.
  4 Tracer
®
The TUC received a Tracer
®
Override verride. Follow Tracer
®
output
commands.
  8 Precool Unoccupied cooling with
economizer, or water;
occupied cooling feasibility
check.
   10 Precool Unoccupied cooling with
EWT economizer while purging
for sampling cold water.
   12 Precool Unoccupied cooling with 100%
cool economizer with water or
compressor augmentation.
 14 Econo- Occupied cooling with econo-
mizer mizer
  16 Econo- Occupied cooling with econo-
mizer mizer while sampling for cold
EWT water.
sampling
