Trane YHC120F - Page 82

Wiring Diagrams
82 RT-SVX21AC-EN
Connection ReliaTel™ 230V
1213-3768 Ultra Low NOx, 4 and 5 Ton, 17-SEER MZ VAV
Connection ReliaTel™ 460V
1213-3769 Ultra Low NOx, 4 and 5 Ton, 17-SEER MZ VAV
Connection Electromechanical 230V
1213-1673 YSC(036-060)G3 Electromechanical Controls
Connection Electromechanical 230V
4366-8390
Y(S,H)C(036,048)E/F, YHC060F (1-Phase),
Electromech
anical Controls
Connection Electromechanical 230V
4366-8392
YHC(036,048)E/F (230V 3-Phase), Electromecha
nical
Controls, X13 IDM
Connection Electromechanical 230V
4366-8404
Y(S,H)C(036-060)E/F (230V 3-Phase), Electromechanical
Controls, Belt-Dri
ve IDM
Connection Electromechanical 230V
4366-8393
YHC060E/F (230V 3-Phase), Electromechanical Controls,
X13 ID
M
Connection Electromechanical 230V
4366-8408 Y(S,H)C(072,090)F (230V), Electromechanical Controls
Connection Electromechanical 230V
4366-8403 YHC120F (3-Phase), Electromechanical Controls
Connection Electromechanical 230V
4366-8406 YSC(092,102)F (230V), Electromechanical Controls
Connection Electromechanical 230V
4366-8400 (YSC120,YHC074-102)F (230V), Electromechanical Controls
Connection Electromechanical 230,460,575V
1213-2660 YSC(072-102)H Electromechanical
Connection Electromechanical 230,460,575V
1213-2661 YSC(092-120)H Electromechanical
Connection Electromechanical 460V and/or 575V
1213-1675 YSC(036-060)G4 Electromechanical Controls
Connection Electromechanical 460V and/or 575V
1213-1677 YSC(036-060)GW Electromechanical Controls
Connection Electromechanical 460V and/or 575V
4366-8394
YHC(036,048)E/F (460V), Electromechanical Controls, X13
IDM
Connection Electromechanical 460V and/or 575V
4366-8405
Y(S,H)C(036-060)E/F (460V,575V), Electromechanical
Controls, Belt-Dri
ve IDM
Connection Electromechanical 460V and/or 575V
4366-8399 YHC060E/F (460V), Electromechanical Controls, X13 IDM
Connection Electromechanical 460V and/or 575V
4366-8389
Y(S,H)C(072,090)F (460V,575V), Electromechanical
Control
s
Connection Electromechanical 460V and/or 575V
4366-8407 YSC(092,102)F (460V,575V), Electromechanical Controls
Connection Electromechanical 460V and/or 575V
4366-8401 (YSC120,YHC074-120)F (460V), Electromechanical Controls
Connection Electromechanical 460V and/or 575V
4366-8402 YSC120F (575V), Electromechanical Controls
(a) Wiring diagrams can be accessed using e-Library by entering the diagram number in the literature order number search field or by contacting technical
support.
Table 29. Wiring diagram matrix
(a)
Schematic Type
Drawing
Number Description
