Tranquil PC SQA-5H - The Front Panel

11/29/2009
3
The front panel
D03_ WHS_PP1_UK
1) HDD carriers
3) Backup
button
2) USB2.0 ports
4) Mode
button
5) Power
button
Back to Index page
The rear panel
D03_ WHS_PP1_UK
1) 12V DC
Power In
2) Desk Lock
3) eSATA
4) Ethernet
5) USB2.0
6) USB2.0
7) USB2.0
8) USB2.0
9) Service panel
Back to Index page
