TransAct DR5000 - Hardware Kit and Parts List

DR5000 READER INSTALLATION GUIDE
403-003-001 Rev A
3
Hardware Kit and Parts List
Table 1-1: Table 1-1: Hardware Kit Parts List
NOTE: A single installation does not use all the hardware included.
Figure 1-2 DR5000 Hardware Kit
Item No. Part Number Description Qty
1 044-024-019 1 X 4, 3.5MM TERMINAL BLOCK 2
2 044-028-C07 M2 X 5 18-8 SS BUTTON-HEAD SOCKET CAP SCREW 1
3 044-028-E32 6-20 X .5 PH PHILLIPS SELF DRILLING 2
4 044-028-E39 6-32 X 3/4 TRUSS HEAD PHILLIP MACHINE SCREW 2
5 044-030-101 M2 STAINLESS STEEL FLAT WASHER 1
6 044-059-122 DR5000 WALL MOUNT BRACKET 1
