6-2 T6-6-50001
T6-6-50002
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
T6-6-50001
Electric Control Group (For 3PH, Non CE)
1
T6-6-50002 Electric Control Group (For 3PH, CE) 1
1 T6-6-50110 Electric Box 1
3 T6-6-50130 Panel 1
4 T6-6-50140 Terminal (Ground) 5
5 T6-6-50150
Terminal (Control)(Single in, single out)
22
6 T6-6-50161 Magnetic Switch 4
7 T6-6-50170
Transformer (For 220V, 380V, 415V/24V)
1
8 T6-6-50180 Fuse Holder 5
Fuse Holder (For CE ) 6
9 T6-6-50190 Relay 2
10 T6-6-50200 Relay Socket 2
11 T6-6-50211 Timer 2
12 T6-6-50220 Magnetic Switch (For Non CE only) 1
13 T6-6-50230 Wire Duct 25x45 1set
14 T6-6-50241 ADD-ON Contact (M2F) (2a) 1
15 T6-6-50250 Rectifier 1
16 T6-6-50261 Over Load Relay 3
17 T6-6-50270 Terminal Guide 1
18 T6-6-50280 Fuse (5A) 3
19 T6-6-50290 Fuse (2A) 2
20 T6-6-50300 End Stop 2
21 T6-6-50310 Terminal (Control)(Two in, two out) 2
22 T6-6-50320 Group Marker Carrier 4
23 T6-6-50330 End Plate (Fuse) 1
24 T6-6-50341 ADD-ON Contact (M2R) (1a1b) 1
25 T6-6-50350 Cover 1
26 T6-6-10250 Earth Plate (6P) (For CE) 1
50 TMS0512 TMS, M5x12 (For CE) 1
51 HBS0616 HBS, M6x16 4
52 SW05 SW, M5 3
53 HBS0510 HBS, M5x10 3
54 PW05 PW, M5 3
ELECTRIC CONTROL GROUP
-69-
11/27/08
