3-1-1
ACCUMULATOR ASS'Y
T6-3-11000
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
T6-3-11000 Accumulator Ass'y (For 12mm) 1
T6-3-11001 Accumulator Ass'y (For 9mm) 1
T6-3-11002 Accumulator Ass'y (For 15.5mm) 1
1 T6-3-11110 Accumulator Bearing Case 1
2 T6-3-11120 Accumulator Lower Shaft 1
3 T6-3-11130 Accumulator Lower Roller 1
4 T6-3-11140 Accumulator Main Roller & Shaft 1
5 T6-3-11150 Accumulator Balance Bar Holder 1
6 T6-3-11160 Accumulator Feed Shooter (For 12mm) 1
T6-3-11161 Accumulator Feed Shooter (For 9mm) 1
T6-3-11162
Accumulator Feed Shooter (For 15.5mm)
1
7 T6-3-11170 Accumulator Lower Shaft Spring Hook 1
8 T6-3-11180 Knob 1
9 T6-3-11190 Bearing Collar 2
10 T6-1-71160 Feed Roller Pulley 1
11 BR6202ZZ Bearing, 6202ZZ 4
12 BR6201ZZ Bearing, 6201ZZ 2
13 BR6902ZZ Bearing, 6902ZZ 2
14 RR35 Snap Ring, H-35 4
15 RR32 Snap Ring, H-32 2
16 RR28 Snap Ring, H-28 1
17 ER12 Snap Ring, E-12 3
18 SR12 Stop Ring, S-12 1
51 HBS0635H HBS, M6x35 (H) 1
52 HSS0615 HSS, M6x15 1
53 HSS0610 HSS, M6x10 2
54 HSS0506 HSS, M5x6 1
55 HN06 HN, M6 1
-42-
