TRAPP TR 200 - Main Components

ENGLISH
23
www.trapp.com.br
Main Components
TR 200
3
1
2
5
7
6
4
8
Image merely illustrative
1. Feeding funnel
2. Knob
3. Body
4. Cutting blades
5. Three-wire connector cable with grounding
6. Branch feed nozzle up to Ø25 mm
7. Motor
8. On/Off Switch
TR 200G
1
4
6
2
3
8
9
5
5
7
Image merely illustrative
12
10
11
Image merely illustrative
1. Feeding funnel
2. Belt stretcher hand wheel
3. Locknut of the belt tensioner
4. Transport wheels
5. Feed hopper attachment handles
6. Body
7. Gasoline Engine
8. Branch feed nozzle up to Ø25 mm
9. Cutting blade
10. Power cut-off button (TRAPP / Lifan motor)
11. Throttle / Choke (TRAPP / Lifan motor)
12. Fuel valve (TRAPP / Lifan motor)
