The UTV mounting
Remove the screws Remove the lid
Take off the switch
Dashboard
Put the switch in
OPERATION
l Pull and turn the clutch knob, so the drum can turn freely by hand.
l Use hand saver bar to hitch the hook of the cable assembly and pull cable to the
load. Attach the cable hook to the load.
WARNING: Check that there are at least five turns of cable remaining on the drum
before operation. Ensure the clutch knob is in the engaged position.
CAUTION: Clutch must be fully engaged before winching.
Never operate the clutch while drum is turning. Do not readjust clutch knob as it has
been adjusted and permanently locked in place with a thread-locking compound in the
factory.
l Press the “IN” button on the ATV/UTV switch to re-spool the cable. Press the
“OUT” button to reverse directions. Wait until the motor stops before reversing
directions.
l Re-spool the cable after completing the operation.
