1
TYPE: YS1115
DESIGNED & MANUFACTURED BY
YORKVILLE SOUND • TORONTO, CANADA
Off
Power
On
BALANCE: The LINK PAN control also functions as a balance
control for the Headphones.
LINK: Use a stereo cable to link two BLOCK 12 units to
create a left and right stereo system. The Link connection
is designed to work with another BLOCK 12 only.
LINK PAN: Use the LINK PAN control to adjust signals being
sent to LINKED BLOCK 12s.
BLOCK
12
IN MEMORY OF
ADIL WILSON
A-Z1615BR/1v0
Left BLOCK 12 Amp Right BLOCK 12 Amp
Traynor Block 10 & Block 12
Block 10 - 200w, 10 inch / 2.5 inch
Block 12 - 200w, 12 inch / 2.5 inch
Today, keyboard players, acoustic guitarists, and other musicians need the ability to travel
light. More importantly they require amplification that maintains the highest standards of fidel-
ity, versatility and reliability. The Traynor Block Series answers those requirements and more.
The Block series is a linear mixing and amplification system built into a versatile combo-style
enclosure. What this means to the pro user is that you can take your Block 10 or 12 anywhere and
do a number of things a PA system would permit. While the Block 10 or 12 are not meant to re-
place a full PA-system, they can be used as one. With the Block 10 or 12 used as a micro PA, the
system fits in a subcompact car with room left for a keyboard, a mic, a stand, a guitar and more.
Traynor’s legendary reliability is a good base on which to build anything. The Block series
offers four inputs; one which accepts a mono or stereo keyboard output, one which accepts
a dynamic microphone or acoustic-electric guitar, one which accepts any line-level signal,
perhaps from a PA mixer, and another which accepts a CD player or other stereo program
source – even a DSP outboard guitar preamp like a *Pod®.
Fully connected, your Block unit can
• Qualitycomponentselectionincludingtheuseofhigh-gradeglassepoxycircuitboards
and low noise components.
• FourinputchannelsutilizinganmicrophonecompatibleXLR,¼-inchTRSphonejacks
and1/8-inch(3.5mm)jacks.
• 2-bandEQonbothChannel1andChannel2.
• 2-wayspeakersystemfeaturesa200-watt10-inchlowfrequencydriver(12-inchon
Block 12) and a 2.5-inch 20-watt high frequency driver .
• Blenduptofouraudiosourcesintoasinglemonomix-down.
• ProfessionalLineOutusingXLRjackwithswitchablepre/post-EQandgroundlift
options.Feedyourmixed,monosignaltoahousePAorrecordingdesk–fully
balanced.
• Helpyourecord,orpracticesilentlywithheadphones(instereo,iftheinputisstereo).
• SupplyastereoLinksignaltoanotherBlockunitifyouwantstereosoundonstage.
• Besetupanywhere.TheBlock10and12havespeakerstandsbuilt-inwhilealso
being able to fit neatly under a keyboard stand or can face you onstage as a monitor.
• Provideclear,accurateperformanceforyearstocome.
*Covered by our famous 2 year unlimited* “Even if you break it” warranty
