Traynor Block 10 - Page 5

3
Channel 1
3. Input Jacks
The¼-inchinputsonChannel1areoptimizedforstereoinstrumentssuchaskey-
boards and synths but mono sources can be also be used (using the left input sums the
stereo audio signals properly).
Note: When using a stereo source with a single Block amp the input will properly sum the
stereo signal.
4. Gain Control
Thelevelforchannel1isadjustedusingtheChannel1Gaincontrol.Ifthelevelistoohot,the
InputChannel1-3ClipLED(nexttothePower/StatusLED)willilluminate.Ifthisoccurs,ad-
justthiscontroluntiltheLEDstopsclippingorclipsverybrieywhenplayinghard.
Note: Boosting the tone controls also affect the level (especially the bass frequencies).
5. Tone Controls
The tone controls, Bass and Treble, cover the entire audio spectrum and can help tailor your
soundaccordingly.Eachcontrolcanboostorcutwitha15dBrangeofadjustment,thecenter
position denotes a 0 dB cut/boost.
Channel 2
6. Input Jacks
AmicrophonecanbeconnectedtoChannel2usingtheXLRjack,foraLine-Levelmonoau-
diosource,usethe¼-inchjack.it’snotrecommendedtousebothinputssimultaneously,use
only one input at a time.
7. Gain Control
Thelevelforchannel2isadjustedusingtheChannel2Gaincontrol.Ifthelevelistoohot,the
InputChannel1-3ClipLED(nexttothePower/StatusLED)willilluminate.Ifthisoccurs,ad-
justthiscontroluntiltheLEDstopsclippingorclipsverybrieywhenplayinghard.
Note: Boosting the tone controls also affect the level (especially the bass frequencies).
8. Tone Controls
The tone controls, Bass and Treble, cover the entire audio spectrum and can help tailor your
soundaccordingly.Eachcontrolcanboostorcutwitha15dBrangeofadjustment,thecenter
position denotes a 0 dB cut/boost.
Channel 3
9. Input Jacks
Channel3’sinputisoptimizedforexternalsourcessuchasdigitalmediaplayers,CDplayers
andtapedecks.The¼-inchand1/8-inchstereojacksareconnectedinparallelandshould
not be used simultaneously. It is suggested to use only one input, at a time, for best operation.
Note: Channel 3 audio does NOT get channeled through to the Line Out .
10. Gain Control
Thelevelforchannel3isadjustedusingtheChannel3Gaincontrol.Ifthelevelistoohot,the
InputChannel1-3ClipLED(nexttothePower/StatusLED)willilluminate.Ifthisoccurs,ad-
justthiscontroluntiltheLEDstopsclippingorclipsverybrieywhenplayinghard.
Channel 4
11. Input Jack
Channel4’sLinelevelinputhasbeenaddedasanextrachannelformonitoringpurposes,the
signaldoesnotmixinwiththemainbusandthustheLineOutnorLinkOutareaffectedbyit.
12. Gain Control
Thelevelforchannel4isadjustedusingtheChannel4Gaincontrol.
