Specifications (cont.)
MECHANICAL
Instrument Dimensions 83 mm H x 318 mm W x 280 mm D
(3.25" H x 12.5" W x 11" D).
Instrument Weight 2 kg (4.4 lb).
Voltage Monitor Connector BNC coaxial connector.
(3 meter length, maximum.)
Ground Receptacle Banana jack.
Battery Eliminator/
Charger Receptacle 2.1 mm DC power plug.
Cable from Instrument to
Floating Plate Coaxial type.
Diameter 4.95 mm (0.195") or
2.6 mm (0.102").
Length 3 m (10 ft), nominal.
IV - 5
