2023 FX+ / Dual Sport+
2
Brake/shi routing
2Nm.
1
2
3
4
5
1
Derailleur hanger bolts (M3x7 mm) – W318604
2
Derailleur hanger – W5268484
3
Rear derailleur cable
4
Rear brake hose
5
Front brake hose
