2023 FX+ / Dual Sport+
1
Safety
WARNING
Tighten hardware properly
Always tighten hardware to the specied torque.
Over-tightening hardware could deform or break the
hardware or components. Under-tightening hardware
could cause hardware or components to become loose.
Either situation could damage the bicycle and result in
injury to the rider.
WARNING
Re-apply threadlocker
All reused-fasteners with a pre-applied threadlocker
must be cleaned with isopropyl alcohol and have new
threadlocker applied before re-assembly. If a threadlock-
er is not applied, the fasteners may loosen, which could
damage the bicycle and result in injury to the rider.
Legend
Apply appropriate grease
Apply threadlocker
Nm
Torque

Cable (zip) tie
More e-bike information
For additional information about the e-bike system, go to
the Electric bikes section at trekbikes.com/manuals.
Contents
Brake/shift routing E-system components
and routing
Battery and controller
assembly
Bottom bracket/torque
sensor
Fork and headset
Chainguard Mudguards and rack Light routing – FX+ Light routing – DS+ Specications
Copyright 2022 Trek Bicycle Corporation All Rights Reserved
Dual Sport+
FX+
