2020 Domane Service Manual
Table of Contents
1. Install common components 2
A. Install and adjust the seatpost 2
B. Install the front derailleur 3
C. Install the rear derailleur 3
D. Install the chain keeper 3
2. Route and install brakes 4
A. Install rear brake in frame 4
B. Install front brake and brake hose 4
3. Route cables and housings through the frame 5
5
5
5
6
6
7
7
7
8
9
9
A. Mechanical
Route front derailleur housing
Route rear derailleur housing Install
the down tube cable guide
Install
the down tube window frame
B. Di2
Route the front derailleur cable
Route the rear derailleur cable
Route battery and install
Install the down tube window frame
Handlebar cable routing
4. Install the fork 11
5. Route and install the stem and handlebar 12
Install the stem 12
Install the handlebar 12
A. Mechanical 13
Connect the brake hose and housing/cables 13
Install the top tube cable guide 13
B. Di2 13
Install the top tube cable guide 13
Install the shift levers 13
6. Domane torque specications 15
7. Service information 16
8. Appendix 17
A. Install the front isospeed 17
B. Install the rear IsoSpeed 20
C. Assemble and install the
DT storage door 22
D. Install the T47 bottom bracket 24
E. Install fenders 25
Install front fender 25
Rear fender chart 26
