2023 Fetch+ 4
3
Steering Dr ivetrain Routing Battery Headsets Frame Accessor ies
Steering: replace steering cables
Replace all four cables every two years or
10,000km/6,000mi.
NOTE: If a cable is damaged and needs repair, replace all
four cables — not just the damaged one.
Remove the cables from the rear disc
1. Cut the three zip ties connecting the steering cables
to the frame (see the zip tie locations on page 1).
2. Loosen the four rear cable mount bolts (2) — do not
remove them.
3. Hold the tensioning bolt (4) in place and use a 13mm
wrench to loosen the tensioning nut (5). Then, loosen
the tensioning bolt to remove tension from the
cables. Repeat for the other side.
4. Remove the two bolts (11) securing the steering
cables in the rear cable mount.
5. Slide the cable mount (6) towards the steering disc to
relieve tension on the cables.
6. Remove the cables from the steering disc.
Remove the cables from the front disc
1. Loosen the two bolts (11) securing the steering
cables in the front cable mount (1).
2. Remove the cables from the front steering disc.
To Next Page
