2023 Marlin 6, 7, 8
3
Cabling – dropper post, no front derailleur
Note: The frame has routing for either a front derailleur or an internally routed dropper post, but not both.
Tip: Remove the bottom bracket to make it easier to route the dropper post housing.
1
2
1
2
3
4
5
1
Rear brake hose
2
Rear derailleur housing
3
Dropper post housing
4
Plug (Use when there is not a front derailleur nor a
dropper post cable housing) — W5271561
5
Foam tubes — W528082
Zip tie
