2023 Marlin 6, 7, 8
4
Cabling – front derailleur, no dropper post
Note: The frame has routing for either a front derailleur or an internally routed dropper post, but not both.
6
3
1
2
3
4
1
2
5
1
Rear brake hose
2
Rear derailleur housing
3
Front derailleur housing
4
Plug (Use when there is not a front derailleur nor a
dropper post cable housing) — W5271561
5
Foam tubes — W528082
(These will need to be cut to size — 450 mm)
6
Cable guide — W575392
Zip tie
