TREND AIR - PARTS LISTS; Complete Kit Components; ACCESSORIES; Charge Cradle

-8-
EN - AIR/PRO
PARTS LISTS
Complete kit
Product Part Number Description
Airshield Pro
UK
AIR/PRO Powered Air Purifying
Respirator incorporating
Eye Protection
Airshield Pro
North EU
AIR/PRO/
EURO
Powered Air Purifying
Respirator incorporating
Eye Protection
Spares - (Fig.12)
Item
No.
Product
Designation
Part
Number
Qty
A
Visor Assembly WP-AIR/P/07 1
B
Head Cover and Face
Seal
WP-AIR/P/03 1
C
Headband Assembly WP-AIR/P/18 1
D
Filter TH2P AIR/P/1 2
E
Battery Pack AIR/P/4 1
F
Battery Charger AIR/P/5/
EURO (EU)
or
AIR/P/5/UK
(UK)
1
G
Airow Indicator WP-AIR/P/02 1
H
On/Off Switch
Assembly
WP-AIR/P/05 1
I
Cover WP-AIR/P/08 1
J
Fan/Motor Assembly WP-AIR/P/01 1
K
Brow Comfort Pad WP-AIR/P/10 1
L
Visor Overlays green AIR/P/3G 10
M
Visor Overlays clear AIR/P/3C 10
N
- - 1
O
Headband Fixing Kit WP-AIR/P/16 1
ACCESSORIES
Charge Cradle
AIR/P/7
SERVICING
Visor overlays (optional)
Install a new set of visor overlays by adhering to the
main visor using the adhesive strips provided.
Visor assembly replacement
• Remove the seven face seal pop studs from visor as
shown in (Fig.6)
• Replace the old or damaged visor assembly as shown
in (Fig.7)
• Release nuts and push screws inwards, release the
front tab and lift visor from the helmet.
• Fit replacement visor ensuring slot in visor locates on
tab and bottom edge in grooves, secure with screws
and nuts.
• Fit visor stiffener wire. Insert the wire ends into the
outer slots provided and rotate to engage securely in
the centre slot.
Visors should be stored out of direct sunlight and
replaced at least every 5 years.
Face seal
Replace the face seal as shown in (Fig.6)
• Starting from the centre of the visor pop studs on
face seal. Release touch and close tape from front of
helmet.
• Unfasten the crown strap on the headband and release
elastic loops on each side.
• Pull face seal over the headband knob and remove
face seal from helmet.
• Tuck edge strip of new face seal under headband and
secure to touch and close tape on helmet. Slip the
elastic loops over the crown strap and adjust strap
length.
• Fit face seal over head band knob and secure to visor
pop studs.
Face seals should be stored out of direct sunlight and
replaced at least every 5 years.
Headband assembly
Remove face seal and visor as shown in (Fig.6) and
(Fig.7). Install a new headband assembly as shown in
(Fig.8)
