VARIJIG - SPARE PARTS DIAGRAM
v1.0 03/2005
3
3
3
3
1
1
1
1
8
8
8
8
4
4
4
4
7
7
7
7
2
2
2
2
5
9
6
10
6
6
6
VARIJIG
VARIJIG
VARIJIG - SPARE PARTS LIST v1.0 03/2005
No. Qty. Desc. Ref.
1 16 T-Nut M4 WP-VJS/01
2 8 Machine Screw Csk M4 x 6mm Pozi Silver WP-VJS/02
3 8 Machine Screw Csk M4 x 6mm Pozi Black WP-VJS/03
4 4 Scale Metric/Imperial 640mm WP-VJS/04
5 1 Anti-Tilt Device WP-VJS/05
6 4 End Cap for Extrusion WP-VJS/06
7 4 Extrusion 700mm Black WP-VJS/07
8 4 Corner Frame Joint WP-VJS/08
9 1 Machine Screw Csk M6 x 25mm Pozi WP-SCW/31
10 1 Manual MANU/VJS
Please use only Trend original spare parts.
