VSD2H Variable Speed Drives Data Sheet TA201104 Issue 3, 08-Oct-2013 11
Data Sheet VSD2H
Order Code
Rated
Continuous
Current I
L
(A)
Low (10%)
overload
current
(A)
Nominal
Motor Shaft
Power P(kW)
at 40 °C
Weight
(kg)
VSD2H/3P-480/003.. 3.4 3.7 1.1 6
VSD2H/3P-480/004.. 4.8 5.3 1.5 6
VSD2H/3P-480/005.. 5.6 6.2 2.2 6
VSD2H/3P-480/008.. 8 8.8 3 6
VSD2H/3P-480/009.. 9.6 10.6 4 6
VSD2H/3P-480/012.. 12 13.2 5.5 6
VSD2H/3P-480/016.. 16 17.6 7.5 10
VSD2H/3P-480/023.. 23 25.3 11 10
VSD2H/3P-480/031.. 31 3 4.1 15 10
VSD2H/3P-480/038.. 38 41.8 18.5 20
VSD2H/3P-480/046.. 46 50.6 22 20
VSD2H/3P-480/061.. 61 67.1 30 20
VSD2H/3P-480/072.. 72 79.2 37 37.5
VSD2H/3P-480/087.. 87 95.7 45 37.5
VSD2H/3P-480/105.. 105 115.5 55 37.5
VSD2H/3P-480/140.. 140 154 75 66
VSD2H/3P-480/170.. 170 187 90 66
VSD2H/3P-480/205.. 205 225.5 110 66
VSD2H/3P-480/261.. 261 287.1 132 108
VSD2H/3P-480/310.. 310 341 160 108
SPECIFICATIONS
Electrical
Supply voltage :380 to 480 Vac ±10% 3 phase,
Frequency :50 to 60 Hz -5, +10%
Connection to mains :once per minute or less
Starting delay :4 s (MR4 to MR6),
6 s (MR7 to MR9)
Motor voltage :0 to supply voltage
Motor current
Rated continuous : I
L
, 3 A to 310 A dependent on option
(see table below)
Low overload : I
L
+ 10%, for 1 minute every 10
minutes, with maximum 40 °C ambient
temperature (see table below).
Starting Current :I
S
, 2 x I
L
(maximum current required for
2 secs every 20 secs).
Output frequency :0 to 320 Hz
Frequency resolution :0.01 Hz
Control method :Frequency control, Open loop
sensorless vector control
Switching frequency :1.5 to 10 kHz
Defaults:
MR4 to 6: 6 kHz (except 0012, 0031,
0064, 4 kHZ)
MR7: 4 kHZ
MR8-9: 3 kHZ
Automatic switching frequency derated
in case of overload
Frequency reference
Analogue input :Resolution 0.1% (10 bit), accuracy ±1%
Keypad reference :Resolution 0.01 Hz
Field weakening point :8 to 320 Hz
Acceleration time :0.1 to 3000 secs
Deceleration time :0.1 to 3000 secs
Braking torque
DC brake :30% T
N
(nominal torque) without brake
resistor
