Rear View
Auto MDI/MDIX 10/100Mbps LAN Port
This port automatically senses the cable type when
connecting to Router.
DC-IN
The DC power input connector is a single jack
socket to supply power to the TEW-690AP. Please
use the Power Adapter provided on the TEW-690AP
package.
Power Switch (EU version)
On/off Switch
Side View
Reset button
Restores device to factory default settings
