Solid Blue – Device is on
Blinking Blue – WPS is activated.
Off – No power
Solid Blue – Internet port is physically connected
Blinking Blue – Data Transmit/Receive.
Off – Internet port is physically disconnected.
Gigabit LAN Ports 1-4
LEDs
Solid Blue – LAN port is physically connected
Blinking Blue – Data Transmit/Receive.
Off – LAN port is physically disconnected.
Solid Blue – 2.4GHz/5GHz
radio is on.
Blinking Blue – Data Transmit/Receive.
Off – 2.4GHz/5GHz
radio is off.
Solid Blue – USB device is connected.
Blinking Blue – Data Transmit/Receive.
Off – No USB device connected.
Application Diagram
The router is installed near the modem (typically supplied by your ISP “Internet Service Provider”)
and physically connected to it from the router’s Internet port to the modem’s network port which
connects to the Internet. 2.4GHz wireless signals from the router are broadcasted to wireless
clients such as laptops (with wireless capability) and the less congested 5GHz wireless signals from
the router are broadcasted to other wireless client devices such as TVs, game consoles, or media
bridges thereby providing Internet access for all wireless client devices.
