MIB
• MIB II RFC 1213
• Bridge MIB RFC 1493
• RMON (Group 1,2,3,9) RFC 2819 RFC 1757
Spanning Tree
• IEEE 802.1d STP (spanning tree protocol)
• IEEE 802.1w RSTP (rapid spanning tree protocol)
• BPDU filter, guard, and root guard
Link Aggregation
• Static link aggregation and 802.3ad dynamic LACP (Up to 3 groups)
Quality of Service (QoS)
• 802.1p Class of service (CoS)
• DSCP (Differentiated Services Code Point)
• Bandwidth control per port
• Queue Scheduling: strict priority (SP), weighted round robin (WRR), weighted
fair queuing (WFQ)
VLAN
• 802.1Q tagged VLAN
• MAC-based VLAN
• Port isolation
• Up to 256 VLAN groups, ID range 1-4094
Multicast
• IGMP snooping v1, v2, v3
• IGMP querier
• IGMP fast leave
• Up to 256 multicast groups
• Static multicast entries
Access Control
• 802.1X authentication (Local user database, RADIUS, guest VLAN assignment)
• DHCP snooping/screening
• Trusted host/IP access list for management access
• Port Security/MAC address learning restriction (Up to 100 entries per port)
• Static/dynamic ARP inspection
ACL
• Source/Destination MAC address
• Source/Destination IP address
• Source Interface
• VLAN ID
• EtherType
• TCP/UDP port 1-65535
Special Features
• Netlite device discovery and map display in GUI
• Port security: MAC address learning restriction per port
• DHCP relay/option 82 & DHCP server snooping/screening support
• Wide operating temperature range
• Dual redundant power inputs
• Alarm relay triggered by power failure
• Surge and ESD protection
Power
• PWR (Primary) terminal input: 24 – 57V DC
• RPS (Redundant) terminal input: 24 – 57V DC
• Compatible power supply: TI-S12024 (120W), TI-S24048 (240W), TI-S48048
(480W) sold separately
• Max. Consumption: 13W (no PoE load), 253W (full PoE load)
