Treyco 3000 - Mount Cutter Blade

Page11

STEP3:MOUNTCUTTERBLADE
1. PlacecutteronholderlabelledOSTERCUTTERbyhavingthe2formed
magnetsfitintothegroovethatthebladeguideridesandthescrewhead
onholderfitsintocutoutincutterwheretheleverfitsthatdrivescutter
backandforthwhenmountedtoclippermotor.
2. WithdiscOFF(notrotating)lowercutterbladetohoningdisc.Visually
checkthatbothteethandwearbararesittingondiscsurface.
3. Liftarmtoverticalposition.
 






Screwhead
Formedmagnets
Bladeguidegroove
Cutoutforlever
Cuttermountedonholder
Teethandrearwearbarboth
sittingondisc
