Treyco 3000 - Reassemble Blade

Page13

STEP6:REASSEMBLEBLADE
1. Tightenspringtensionifneededbysqueezingspringwhereshapedlike
horseshoewithpliersclosingtheopeningofthehorseshoeslightly,donot
closesomuchthatsocketcannotslidebackintospring,ifyouhave
overtightenedbendhorseshoeopenwithflatbladescrewdriver.
2. Assemblespringandsockettogetherandattachtocombbladewith2
screws.
3. Aligncuttertocombandexaminetipsofcutterteethinrelationtotipsof
combteeth,cutterteethshouldbeslightlybehindcombteethsothesharp
needleliketipsofthecutterteetharenotprotrudingpastthecombteeth
asthiscouldscratchorcutthesurfaceoftheanimalorpersonthebladeis
beingusedon.(seechart)
4. Placebladeonclippermotorandturnon,ifbladerattlestheearsofthe
socketmustbesqueezedclosertogethertoeliminaterattle(thiscanbe
donewithoutdisassemblingblade).
5. Testcutonrabbitpelt.



 


Tightening
springtension
Adjustingsocket
earstostop
bladerattle
Cuttersetback
