Triax TDH 800 Configuration Guide

Introduction
4
Service tool
1. Open a web browser window.
2. Enter ‘http://192.168.0.100’ in the web address field.
3. Press Enter.
4. Enter the password.
5. Press the Log in button.
Note:
Password = ‘triax1234’ when the service tool is opened for the first time.
The Keep me logged in checkbox overrides the system’s automatic
time out function, which is activated after 20 minute’s inactivity.
Introduction
5
Overview
Icons
Indicates whether the service tool is communicating correctly with the
headend unit.
Green
The service tool and headend are communicating
correctly.
Red
The service tool and headend are NOT communicating
correctly.
Indicates whether the headend unit is functioning correctly.
Green
The headend unit is functioning correctly.
Red
The headend unit is functioning correctly.
Communication
icon
System icon
Configuration
buttons
Tabs
Misc.
Buttons
