< tv >
Plug in devices that require continuous
power and devices with hard disk drives
into the always-on outlets (e.g., DVR and
set-top box).
TAV-Link function (optional):
Peripheral electronics that are capable of
receiving Consumer Electronic Control
(CEC) commands via HDMI should still
be plugged into the always-on outlets and
will be safely switched off and placed into
an energy-saving mode (see step 5).
always on
Plug the TV into the control outlet
marked <tv>.
Note: The TV must be plugged into
this outlet.
Remove the backing from the
double-sided tape on the top of the
multi-sensor. Affix the multi-sensor to
or near the TV's remote sensor.
Ensure that the distance is less than
eight feet from the power strip.
Step 5
TAV-LINK CAPABILITY
–OPTIONAL–
Step 6
If you have a TV with HDMI inputs,
plug the TAV-Link cable into an open
HDMI port on the TV. TAV-Link
functionality will softly switch off (or
place into an energy saving mode)
HDMI-connected peripherals capable
of receiving CEC commands after no
IR remote control activity or motion is
detected.
TAV-LINK CABLE SOLD SEPARATELY
www.tricklestar.com
AV Advanced Powerstrip+
Step 7
Plug the power strip into a grounded
receptacle. The ground and surge
lights on the power strip will
illuminate, indicating the that power
strip is properly grounded and that
surge protection is active.
Step 4
Plug the multi-sensor into the port
on the side of the power strip that
looks like a phone jack and marked
“sensor”.
Step 3
switched
dvd
subwoofer
Plug the AV peripheral electronics into
the switched outlets.
Note: all four switched outlets operate
the same way. The icons serve only
as examples of AV equipment that
can be plugged into these outlets.
