Use peripheral remote controls to
turn on electronics as needed.
Step 3
When finished watching TV, press the
power button on the remote control to
switch off the TV. All switched outlets
will then automatically turn off after 1
minute.
Step 4
Energy Saving
IR + Motion Sensing
Countdown Timer Operation
For the first 15/30/60 minutes - the multi-sensor senses for IR only.
For the next 15/30/60 minutes - the multi-sensor senses for IR signal and motion.
If no IR or motion has been sensed during the 30/60/120 minute countdown
period, the switched outlets will switch off automatically.
Switched outlets
switch on
User switches
TV on
15/30/60 min countdown timer
starts
IR remote control button
press detected?
Next 15/30/60 min countdown
timer starts
IR or motion detected?
No
No
Yes
Yes
User presses IR
remote control
ALERTS START
Buzzer sounds at 10 min and
3 min before countdown timer
expiration.
Red and blue dual-color LED
flashes
TV & peripherals switch off
TAV-Link sends commands to soft-switch
off HDMI-connected peripherals plugged
into the always-on and switched outlets
IR - Infrared remote control signal
PIR Sensor - Multi-sensor uses passive infrared sensing to detect motion
Motion - Motion detected by PIR
Countdown Timer - Time before the switched outlets are automatically switched off
Countdown Period - 30/60/120 minutes (default - 60 min.)
LED - Red and blue dual-color LED located in multi-sensor
- When IR or motion is sensed, the red LED will flash
Buzzer - Buzzer located in the multi-sensor
Terms
www.tricklestar.com
AV Advanced Powerstrip+
