1. Introduction
1.1.Lock structure
1.2.Packing List
Check the following drawing to check whether the package contains all the parts
NO Name Qty NO Name Qty
1
Front Pane
1
11
Sliding Screws:M5*10mm
2
2
Back Panel
1
12
Mortise Screws:M*10MM
(For Aluminum Door)
4
3
Mortise
1
13
Mortise Screws M4*25mm
(For Wooden Door)
4
4
Card
3
14
M5*25mm Screw
1
5
Mechanical Key
2
15
M5*30mm Screw
1
6
Waterproof Rubber
Plate
2
16
M5*40mm Screw
1
7
U-Clip
1
17
M5*50mm Screw
1
8
User Manual
1
18
M5*70mm Screw
1
9
Strike&Strike Box
1+1 19
60mm Square shaft
1
10
Screw Stubs:M5*35mm
2
20
80mm Square shaft
1
Fingerprint
Battery Box
Mech. Key
USB Port
310mm
39mm
Touch Keypad
Card Reader
155mm88mm67mm
23mm
49mm
127mm
