13. TECHNICAL DATA
Remarks:
(1) Machine weight: refers to the overall machine weight without the batteries, and with both tanks empty.
(2) Machine weight during transport: refers to the overall machine weight with the batteries, but with both tanks empty.
(3) Machine weight during work operations: refers to the overall machine weight with the batteries, with the solution tank full and the detergent canister full (valid for HDC versions), but with the recovery
tank empty.
11
TECHNICAL DATA
US
cu
TRIDENT
T20 SC
Rated machine power W 1075
Working capacity up to ft
2
/h 26802
Working width in 20
Squeegee width in 28
Brush head brush diameter in 20
Number of brush head brush rotations rpm 140
Brush head motor (voltage / nominal power) V - W 24 - 500
Maximum weight exerted on the brush head lb 79,4
Maximum possible gradient for uphill and downhill movement
(weight
(2)
)
% 10
Maximum slope during ascent and descent with the transport
program (weight
(2)
)
% 10
Maximum ambient temperature for machine operation °F 104
Minimum ambient temperature for using the machine's scrubbing
functions
°F 32
Traction motor (voltage / rated power) V - W 24 - 150
Traction wheel (external Ø / width) in 8,9 x 2,6
Maximum forward speed in transport mode mph 3
TECHNICAL DATA
US
cu
TRIDENT
T20 SC
Vacuum motor (voltage - nominal power rating) V - W 24 - 424
Vacuum on vacuum head psi 1.75
Maximum solution tank capacity gal 13,9
Maximum recovery tank capacity gal 14,3
Turning circle in -
Machine dimensions (length - width - height) in 51,2 - 22 - 43,2
Battery compartment dimensions (width - length - useful height) in 13,8 - 7 - 11
Recommended battery
n° - V -
AhC5
2 - 12 - 112
Machine weight
(1)
lb 247
Machine weight during transport
(2)
lb 419
Machine weight during work operations
(3)
lb 536
Maximum battery weight (recommended) lb 86
Sound pressure level (ISO 11201) - L
pA
dB (A) <70
Uncertainty K
pA
dB (A) 1,5
Hand vibration level (ISO 5349) m/s
2
<2,5
Vibration measurement uncertainty -
