Tridonic BASIC Series - Battery Data; Battery Selection; Battery Charge; Discharge Data

www.tridonic.com
12
Subject to change without notice. Information provided without guarantee.
Data sheet 09/22-EM080-23
Emergency lighting units
EM converterLED
7. Battery data
7.1 Battery selection
EM converterLED BASIC, 1 / 3 h, NiMH
Type
EM converterLED BASIC 202A MH/
LiFePO4 250V
EM converterLED BASIC 203 MH/
LiFePO4 250V
EM converterLED BASIC 204 MH/
LiFePO4 250V
EM converterLED BASIC 205 MH/
LiFePO4 250V
Article no. 89800709 89800592 89800581 89800582
Duration
1 h 3 h 1 h 3 h 1 h 3 h 1 h 3 h
Battery charge
time
Initial charge 24 h
Fast recharge 24 h
Trickle charge continuously
Charging current
Initial charge 110 – 150 mA 190 – 230 mA 110 – 150 mA 190 – 230 mA 110 – 150 mA 190 – 230 mA 110 – 150 mA 190 – 230 mA
Fast recharge 110 – 150 mA 190 – 230 mA 110 – 150 mA 190 – 230 mA 110 – 150 mA 190 – 230 mA 110 – 150 mA 190 – 230 mA
Trickle charge
110 – 150 mA /
4 min.
0 mA / 16 min.
190 – 230 mA /
4 min.
0 mA / 16 min.
110 – 150 mA /
4 min.
0 mA / 16 min.
190 – 230 mA /
4 min.
0 mA / 16 min.
110 – 150 mA /
4 min.
0 mA / 16 min.
190 – 230 mA /
4 min.
0 mA / 16 min.
110 – 150 mA /
4 min.
0 mA / 16 min.
190 – 230 mA /
4 min.
0 mA / 16 min.
Discharge current 780 – 840 mA 780 – 840 mA 840 – 900 mA 840 – 900 mA 850 – 910 mA 850 – 910 mA 860 – 920 mA 860 – 920 mA
Charge voltage range
1
0.9 – 1.65 V per cell
Discharge voltage range 1.65 – 1.05 V per cell
1
The battery will be charged below 0.9 V. The EM converterLED will indicate a battery fault.
The emergency lighting LED driver will recharge the battery normally after running the test of 61347-2-7 CL 22.3 (abnormal operating conditions).
7.2 Battery charge / discharge data
EM converterLED BASIC, 1 / 3 h
Type
EM converterLED BASIC
202A MH/LiFePO4 250V
EM converterLED BASIC
203 MH/LiFePO4 250V
EM converterLED BASIC
204 MH/LiFePO4 250V
EM converterLED BASIC
205 MH/LiFePO4 250V
Article no. 89800709 89800592 89800581 89800582
Duration 1 h 3 h 1 h 3 h 1 h 3 h 1 h 3 h
Technology
and capacity
Design Number
of cells
Type
Article no. Assignable batteries
NiMH 4 Ah
LA cells
stick 1 x 3 Accu-NiMH 4Ah 3A CON  • •
stick 1 x 4 Accu-NiMH 4Ah 4A CON  •
stick + stick 2 + 2 Accu-NiMH 4Ah 4C CON  •
stick + stick 2 + 3 Accu-NiMH 4Ah 5C CON  •
remote box 1 x 3 Pack-NiMH 4Ah 3 CON  • •
remote box 1 x 4 Pack-NiMH 4Ah 4 CON  •
LiFePO
4
1.5 Ah
18650 cells
stick 1 x 1 Accu-LiFePO4 1A CON  •
stick 1 x 2 Accu-LiFePO4 2A CON  • • •
stick 1 x 3 Accu-LiFePO4 3A CON  •
stick 1 x 4 Accu-LiFePO4 4A CON  •
stick 1 x 5 Accu-LiFePO4 5A CON  •
stick 1 x 6 Accu-LiFePO4 6A CON  •
stick + stick 2 + 2 Accu-LiFePO4 4C CON  •
stick + stick 2 + 3 Accu-LiFePO4 5C CON  •
stick + stick 3 + 3 Accu-LiFePO4 6C CON  •
side by side 2 x 1 Accu-LiFePO4 2B CON  • • •
side by side 3 x 1 Accu-LiFePO4 3B CON  •
side by side 4 x 1 Accu-LiFePO4 4B CON  •
side by side 5 x 1 Accu-LiFePO4 5B CON  •
side by side 6 x 1 Accu-LiFePO4 6B CON  •
remote box 1 x 1 PACK-LiFePO4 1.5Ah 1 CON  •
remote box 1 x 2 PACK-LiFePO4 3.0Ah 2 CON  • • •
remote box 1 x 3 PACK-LiFePO4 4.5Ah 3 CON  •
remote box 1 x 4 PACK-LiFePO4 6.0Ah 4 CON  •
