Product manual basicDIM DGC | 07-2018 | 1.9 | en
Room profiles
c
33 / 48
6.1.3. Table of functions
Function
Description
PowerOn behaviour
= Presence state
T1 effective range = Only Output 1
T1 short press = ON and OFF
T1 long press = dimming
T1 double click = Saving enabled
=> Luminaires at both outputs flash twice (pause for 5 s between double clicks)
T2 effective range = Only Output 2
T2 short press = ON and OFF
T2 long press = dimming
T2 double click = Saving enabled
=> Luminaires at both outputs flash twice (pause for 5 s between double clicks)
Relays = standby
Constant light control BrightOUT = enabled, dimming out after 10 minutes
Constant light control output 1 = automatic
Constant light control output 2 = automatic with offset of -30% (compared to CH1)
...
