Tridonic DALI basicDIM DGC User Manual

Product manual basicDIM DGC | 07-2018 | 1.9 | en
Functions
c
10 / 48
The DALI basicDIM DGC has the following functions and user interfaces:
5.1. Basic functions
5.1.1. PowerOn behaviour
The PowerOn behaviour determines the behaviour of the basicDIM DGC when .it is switched on and off The following commands are
transferred at PowerOn.
CH1 DALI CH1 eD CH2 DALI CH2 eD
PowerON
- -
the settings of the The adjustable parameters MIN LEVEL SET, SET MAX LEVEL are taken from basicDIM DGC.
5.1.2. Behaviour in normal operation
In normal operation the following parameters are transferred:
CH1 DALI CH1 eD CH2 DALI CH2 eD
Normal
operation
-
The eD-parameter QUERY TYPE CONTROL NUMBER checks whether an additional basicDIM DGC is connected to CH2 (which
corresponds to basic configuration).
If this is the case, the DALI IN port will be disabled.
Basic functions_
Constant light control by means of ambient light sensor_
Presence-based control by means of PIR motion sensor or presence detector_
Remote control via an infrared input for two different IR remote controls_
DTR0_
SET POWER ON LEVEL_
SET SYSTEM FAILURE LEVEL_
SET MIN LEVEL (adjustable)_
SET MAX LEVEL (adjustable)_
SET FADE TIME_
DTR0_
SET POWER ON LEVEL_
SET SYSTEM FAILURE LEVEL_
SET MIN LEVEL (adjustable)_
SET MAX LEVEL (adjustable)_
SET FADE TIME_
DAP_
QUERY LAMP
FAILURE
_
DAP_
QUERY LAMP
FAILURE
_
QUERY CONTROL TYPE
NUMBER
_
