Tridonic DALI basicDIM DGC User Manual

Product manual basicDIM DGC | 07-2018 | 1.9 | en
Room profiles
c
45 / 48
6.5.3. Table of functions
Function
Description
PowerOn behaviour
= Presence state
T1 effective range = Output 1
T1 short press = ON and OFF
T1 long press = dimming
T1 double click = Saving enabled
=> Luminaires from output 1 will flash twice
T2 effective range = Output 2
T2 short press = ON and OFF
T2 long press = dimming
T2 double click = Saving enabled
=> Luminaires from output 1 will flash twice
Relays = standby
Constant light control BrightOUT = enabled, dimming out after 10 minutes
Constant light control output 1 = automatic
Constant light control output 2 = manual
Presence control mode = ON/OFF
Presence control run-on time = 10 min
