SPECIFICATIONS
Function TriField
®
EMF Meter
AC Magnetic 3 - axis
Frequency Range 40 Hz - 100 kHz
Accuracy ±4% @ 50/60 Hz
Maximum Range 100.0 mG
Resolution 0.1 mG
Frequency Response See plot below
AC Electric 1 - axis
Frequency Range 40 Hz - 100 kHz
Accuracy ±5% @ 50/60 Hz
Maximum Range 1000 V/m
Resolution 1 V/m
Frequency Response See plot below
RF/Microwave 1 - axis
Frequency Range 20 MHz - 6 GHz
Accuracy ±20% @ 1 GHz
Maximum Range 19.999 mW/m
2
Resolution 0.001 mW/m
2
Frequency Response See plot below
Battery 9V alkaline battery
Battery Life Backlight O > 20 hrs
Battery Life Backlight On > 12 hrs
Frequency Response
AC Magnetic AC Electric RF/Microwave
7
