TECHNICAL DATA
LiveLink LAN…
…
DR
...
DR C
onnect
...
DR+RC
Input voltage 220-240 VAC
Input current (nominal) 70 mA
Input frequency 50 / 60 Hz
Standby power
consumption
N/A
D
ALI current 180 mA
DALI devices
(stand-alone operation)
ma
x. 64
DALI groups
(stand-alone operation)
ma
x. 16
DALI cable length max. 300 m
L cable length max. 25 m
Number of light scenes
(stand-alone operation)
max. 50
Number of radio
modules
--- ma
x. 50
ZigBee --- IEEE 802.15.4
ZigBee range
---
max. 30 m (in
open field)
Service life 50,000 h
Standards
---
EN 301489-1
EN 301489-17
EN 300328
EN 61347-2-11
EN 62386-101
EN 62386-103
EN 55024
EN 55032
ENEN
Disposal of waste electrical and electronic
equipment
Always collect and dispose of old electrical
and electronic equipment separately at the
end of its service life. In case of doubt, seek
information about environmentally-compliant waste
disposal from your local district authority or special
waste disposal companies. Current information on the
energy efficiency class of the selected product version
can be found in the corresponding data sheet for the
luminaire. Instructions for replacing or removing the
light source in accordance with Regulation 2019/2020/
EU can be found at:
www.trilux.com/EcoDesign
Intended use
Intended for indoor use with a maximum ambient
temperature of: ta 50 °C
Safety class: I
Protection rating:
IP20
Important notes on the status LED
Each DALI channel has its own status LED.
• Status LED glows green: system is booting.
• Status LED glows continuously and flickers occa-
sionally: normal operation (gateway communicating
with devices and server).
• Status LED flickers continuously: high communica-
tion load (e.g. active DALI scan)
• Status LED flashes (approx. every 0.5 s): gateway is
not connected to the server or logged in.
Directive 2014/53/EU
Simplified EU Declaration of Conformity according
to the RED Directive if the luminaire is equipped
with a control gear unit with NFC interface or a radio
component:
TRILUX hereby declares that the following radio sys-
tem type complies with Directive 2014/53/EU:
The full text of the EU Declaration of Conformity is
available on the Internet at:
www.trilux.com/eu-conformity
