3
Lift the Gearbox Assembly clear of
the Procut and place on a bench.
Remove ALL Lifting Equipment
from the Gearbox Assembly.
Flip the Gearbox Assembly over to
the position shown.
Note:
Place the Gearbox Assembly on
cardboard or rubber to minimise paint
damage!
PROCUT 178 and 210 Only:
Slacken the three M8 x 40 Bolts
highlighted.
Tap the heads of each of the Bolts
with a Hammer.
This will separate the Pulleys off the
Biloc Bush.
Remove the M8 x 40 Bolts.
Remove the first Pulley.
