PROCUT 178 and 210 Only:
Insert a Flat Bladed Screwdriver in
the Slot in the Biloc Bush.
Carefully lever the Bush open
slightly.
Slide the Bush up and off the Gearbox
Output Shaft.
Remove the second Pulley.
PROCUT 178 and 210 Only:
Clean the Taper in the centre of
BOTH Gearbox Pulleys using White
Spirits and a Clean Cloth.
Clean the Welded 33mm Biloc Bush
using White Spirits and a Clean
Cloth.
One Pulley is shown opposite.
PROCUT 178 and 210 Only:
Lay one Pulley as shown and fit the
Welded 33mm Biloc Bush into the
Pulley with the LONG side of the
taper facing DOWNWARDS as
shown opposite.
Insert Flat Screw
driver here to
lever bush open
slightly
Long side of Biloc
Taper MUST face
DOWNWARDS!
