Trimax S3 - Page 5

5
PROCUT 178 and 210 Only:
Fit the Second Pulley over the
Welded 33mm Biloc Bush.
Fit the three M8 x 40 bolts into the
Pulley.
Note:
DO NOT tighten the M8 x 40 bolts at
this stage!
PROCUT 237 and 290 Only:
Remove the two Grub Screws
highlighted.
PROCUT 237 and 290 Only:
Re-insert one of the Grub Screws in
the hole highlighted.
Gradually tighten until the Pulley
separates from the Taper Lock Bush.
Continue to tighten this Grub Screw
to drive the Taper Lock Buch
upwards.
