Trimax Snake - Mount and Secure Wheel; Lower Mower and Remove Jack

11
Fit the Wheel to the wheel hub.
Nip up the Wheel Nuts to secure
using the pattern shown.
The Tapered ends of the Wheel Nuts
face the Wheels.
Note:
The Wheel Nuts will be torqued once
the Chassis is lowered to the ground.
Remove the safety block from under
the mower.
Lower mower to the ground and
remove jack.
1
2
3
4
5
