Trimax Snake - Secure Axle with Split Pin; Install Bearing Buddy

10
Insert the Split Pin (201-447-000)
through the Castle Nut and the hole in
the end of the Axle Stub.
Bend the Legs of the Split Pin around
the Nut.
Note:
The Short Leg of the Split pin may
require trimming with Snips to clear
the Washer and Bearing.
Fit the Bearing Buddy (416-000-098).
Gently drive home until fully seated
in the Hub.
IMPORTANT:
Fill the Bearing Buddy completely
with grease before fitting.
Some mowers may use a grease cap.
