B Data Formats
140 Trimble M3 Total Station User Guide
Area
Calculation
x x AREA
x CCCCC PPPPPPPPPPPP SD Hz Vk
meas. pt. P
x CCCCC PPPPPPPPPPPP Y X Z
meas. pt. P
x CCCCC PPPPPPPPPPPP Y X Z
input (or from MEM) pt. P
x x AREA Fl
Unknown
station
x x UN STAT
x A PPPPPPPPPPPP Y X
reference point A, B, C, D, E
x A PPPPPPPPPPPP SD Hz Vk
measurement to A, B, C, D, E
x A PPPPPPPPPPPP vy vx vz
residual point A, B, C, D, E
x x S PPPPPPPPPPPP Y X
station coordinates
xx m Oms0
scale, orient., standard
deviation
Known station x x KN STAT
x S PPPPPPPPPPPP Y X
station coordinates
x A PPPPPPPPPPPP Y X
reference point A
x A PPPPPPPPPPPP Hz Vk
measurement to A (Hz, V mode)
x A PPPPPPPPPPPP SD Hz Vk
measurement to A (SD, Hz, V
mode)
xx Om
orientation (Hz, V)
xx m Om
scale, orientation (SD, Hz, V)
Station
elevation
x x EL STAT
x x ! PPPPPPPPPPPP Z
height of A
x A PPPPPPPPPPPP SD Hz Vk
measurement of A
x x S PPPPPPPPPPPP Z
computed station height
Meas. Topo. x x POLAR
x CCCCC PPPPPPPPPPPP SD Hz Vk
original readings
x CCCCC PPPPPPPPPPPP Y X Z
coordinates
x x CCCCC PPPPPPPPPPPP T
eccentricity Tv, Th, Tl, Tr, Ts
Table B.7 Recording data lines (continued)
Mode Rec
1
Mode
2
Content of record
P, C , I
T1 T2 T3
Comments
