Trimble M3 Total Station User Guide 35
Before Going to the Field 3
The angle settings are:
Distance settings
1. From the
Settings Instrument menu,
select
[2] Distance,
To move from one line to the next, press
[v].
2. To change the settings in each line, press
[<] or [>]
and then press
[MEAS/ENT] to confirm the change.
The distance settings are:
Options
Accuracy Trimble M3 3"DR
1" / 0.0002° / 0.2mg / 0.01M
5" / 0.001° / 1mg / 0.1M
10" / 0.005° / 5mg / 0.5M
Trimble M3 5"DR
1" / 0.0005° / 0.5mg / 0.01M
5" / 0.001° / 1mg / 0.1M
10" / 0.005° / 5mg / 0.5M
Unit DMS
Deg
gon
mil
V-Reference Zenith
Vertical
± Elev
AZ-Zero-Direct North
South
HA Initialize ON
OFF
Note – When HA Initialize is set to ON, the horizontal angle needs to be
initialized (by rotating alidade) every time the vertical index is initialized
(that is, when you turn the instrument on). By doing this, the azimuth
direction will be kept after rebooting the instrument.
Options
Accuracy 0.001 m / 0.001 ft
0.005 m / 0.01 ft
0.01 m / 0.02 ft
Unit Meter
United States foot (U-ft)
International foot (I-ft)
