Trimble R1 Quick Start Guide

LED information and power off
3
GNSS
- - -
Pairing mode N/A
--- --- ---
--- --- ---
--- --- ---
------ ------ ------
Solid
Corrected
Bluetooth / GNSS LED
3. Bluetooth connection Power LED Turn off
When LEDs = ,
release Power button.
After a few seconds,
LED = --- --- ---
1.
2.
Hold Power button
LED =
LED =
When LED = Off
and LED = ,
release the Power
button.
Both LEDs = Off
Solid
<100%
Solid
100%
Off
>50%
--- --- ---
<50%
--- --- ---
<15%
- - -
*On Android devices, enable Mock Locations. See the Trimble R1 GNSS
Receiver User Guide for more information.

Trimble R1 Specifications

General

Receiver Type	GNSS
GNSS Signals Tracked	GPS, GLONASS, Galileo, BeiDou, QZSS
Channels	44
SBAS	Yes
Data Logging	Yes
Bluetooth	Yes
Wi-Fi	No
Weight	187 g (6.6 oz)
Operating Temperature	-20 °C to +60 °C (-4 °F to +140 °F)
IP Rating	IP65
Connectivity	Bluetooth
Dimensions	11.2 cm x 6.8 cm x 2.7 cm (4.4 in x 2.7 in x 1.1 in)
