radartransmittercanoverwhelmthereceivercircuits.Thisdoesnotharmthereceiver,
butcanpreventthereceiverelectronicsfromfunctioningcorrectly.
Low‐powertransmitters,suchasthoseincellphonesandtwo‐wayradios,donot
interferewithreceiveroperations
 Donotsetupthe
basestationdirectlybeneathorclosetooverheadpowerlinesorelectrical
generationfacilities.Theelectromagneticfieldsassociatedwiththeseutilitiescaninterfere
withGNSSreceiveroperation.Othersourcesofelectromagneticinterferenceinclude:
 Gasolineengines(sparkplugs)
 Televisionsandcomputermonitors
 Alternatorsandgenerators
 Electricmotors
 EquipmentwithDC‐to‐ACconverters
 Fluorescentlights
 Switchingpowersupplies
 PlacetheGNSSreceiversinaprotectedandsecurelocation.Ifthebasestationisinthecenter
ofajobsitewhereheavymachineryisoperating,placeflagsaroundthebasestationto warn
operatorsof
itsexistence.
 Ifyouplacethereceiverinalockboxonthejobsitetoprotectthereceiverfromtheftorfrom
theweather,shieldthelockboxfromdirectsunlightandprovideventilationforthereceiver
throughaninletandextractorfan.Areceiverthathasabroadcast
radiogeneratessignificant
heat.Donotallowthetemperatureintheboxtoexceed50°C(122°F).
Ifworkinginacoldclimate,youmayneedtoprovideheattothereceiver.Donotoperatethe
receiverbelow–40°C(–40°F)
 Trimblerecommendsthat,whereverpossible,youkeep
GNSSreceiverequipmentdry.The
receiversaredesignedtowithstandwetweather,butkeepingthemdryprolongstheirlifeand
reducestheeffectsofcorrosiononportsandconnectors.Iftheequipmentgetswet,usea
cleandryclothtodrytheequipmentandthenleavetheequipmentopento
theairtodry.Do
notlockwetequipmentinatransportcaseforprolongedperiods.Avoidexposingthereceiver
tocorrosiveliquidsandsaltwaterwhereverpossible.
 Trimblerecommendsthatyouinstalllightningprotectionequipme ntatpermanentbase
stationlocations.Equipmentshouldincludeagascapsulelightningprotectorin
theGNSSand
radioantennafeedlineandappropriatesafetygrounding.Astaticdissipaternearthe
antennascanreducethelikelihoodofadirectlightningstrike.Alsoprotectany
communicationsandpowerlinesatbuildingentrypoints.Formoreinformation,contactyour
localTrimbledealer,orgototheHuber
andSuhnerwebsite(www.hubersuhnerinc.com).
 Trimblerecommendsthatyouusesurgeprotectionequipmentonallpermanentlyinstalled
equipment.


Trimble R10 Specifications

General

Channels	440
RTK Horizontal Accuracy	8 mm + 1 ppm RMS
RTK Vertical Accuracy	15 mm + 1 ppm RMS
Operating Temperature	-40 °C to +65 °C
L1 C/A Code	Yes
L2E	Yes
L2C	Yes
L5	Yes
Beacon	No
FM Radio	No
WAAS	Yes
MSAS	Yes
EGNOS	Yes
Storage Temperature	-40 °C to +75 °C
Ingress Protection	IP67
Positioning Accuracy (Static) - Horizontal	3 mm + 0.5 ppm RMS
Positioning Accuracy (Static) - Vertical	5 mm + 0.5 ppm RMS
Signal Tracking	BeiDou
RTK Initialization	< 8 seconds
Battery Life	Up to 7 hours
SBAS Accuracy	50 cm
Glonass Code	L1 C/A, L2 C/A
Communications	Bluetooth
