Trimble R10 - Receiver Configuration - Tracking; Elevation Mask

TrimbleR10ReceiverWebHelp
ReceiverConfiguration–Tracking
ElevationMask–Entertheelevation,indegrees,belowwhichthereceiverwillnottracksatellites.
Everest™MultipathMitigation–Trimbleproprietarymultipathmitigationalgorithm.Enabledby
default.
ClockSteering–Whenenabled,thereceiverclockissteeredtoGPSsystemtimeratherthan
periodicallyintroducing1msstepsandconstrainingthe
clockto±0.5ms.Enabledbydefault.

Type Signal Description
L2 SetwhichinformationoftheL2signalthereceiveristoobserve.
L2–
Legacy
ThereceiverwilltrackthefullcyclecarrierphaseoftheL2signal.CScode
willnotbetrackedevenifavailable.
L2CSwith
Legacy
fallback
ThereceiverwilltracktheCScodeontheL2signalifavailable.IfCScodeis
notavailable,thereceiverwilltrackfullcyclecarrierphaseinLegacymode.
L2CSwith
Legacy
ThereceiverwilltrackbothCSandLegacycodesimultaneously.
L2–CS ThereceiverwilltracktheCScodeontheL2signalifavailable.IfCScodeis
notavailable,thereceivertracksfullcyclecarrierphaseinLegacymode.
L2CS–
CM/CL
ThereceiverwilltrackboththeCMandCLcodebroadcastbythesatellite
simultaneously.Trimblerecommendsthatyouusethissetting.
L2CS–CL ThereceiverwilltrackonlytheCLcodebroadcastbythesatellite.
GPS
GPSL5 IfL5isinstalled,thismenuitemisdisplayed.Ifselected,itallowstracking
oftheL5signal.SetwhichcodethereceiveristotrackontheL5signal:L5
–Q–ThereceiverwilltrackonlytheQcodebroadcastbythesatellite.L5–

I+Q–ThereceiverwilltrackboththeIandQcodebroadcastbythe
satellitesimultaneously.Trimblerecommendsthatyouusethissetting.
L1‐C/A EnableordisablethetrackingoftheL1C/AsignaltransmittedfromaSBAS
satellitessuchasWAAS.
SBAS
L5 EnableordisablethetrackingoftheL5C/AsignaltransmittedfromaSBAS
satellitessuchasWAAS.
L1 EnableordisablethetrackingofGLONASSsignalsbythereceiver.
CAandP ThereceiverwillsimultaneouslytrackboththeCAandPcodeofthe
GLONASSsatelliteifbothareselected.Thisistherecommendedsetting.
GLONASS
L2 Selectfromthefollowingoptions:Disable,L2‐C/A(M),L2‐P.L2‐Pisthe
recommendedsetting.
E1 EnableordisablethetrackingofGALILEOsignalsbythereceiver.
E5‐A EnableordisablethetrackingoftheGALILEOE5‐Asignalbythereceiver.
GALILEO
E5‐B EnableordisablethetrackingoftheGALILEOE5‐Bsignalbythereceiver.
