Trinity Highway CASS TL3 - Page 12

TrinityHighway.com 11 Revision A November 2021
PN: 6722G
PN: 9021G
PN: 33901G
5/8" X 8" ATR CHSL PT A449
Bearing Angle
C-Shaped Driven Post
PN: 33902G
PN: 33903
PN: 33908G
C-Shaped Post
Driven S3 Terminal Posts
w/Soil Plates-Posts 4-9
Terminal Post Sleeve–S3
Post
PN: 33909G
PN: 33910G
PN: 33912G
CRP-Cable Bracket
S3 Terminal Post – in Sleeve
Splice Post in Sleeve
PN: 33915A
PN: 33916B
PN: 33934A
Base Plated Post
CRP Reinforcing Cage
Bottom CRP (in Concrete)
