TrinityHighway.com 33 Revision A November 2021
CASS
®
Assembly/Repair Checklist
(File With Project/Maintenance Records)
Performed by:
Date:
Location: ______________________________________________________________________
1. Ensure only Trinity Highway CASS
®
parts are used for the assembly/repair of CASS
®
and
that all parts are free of damage. (p 4)
2. Ensure required traffic control is in place to conduct CASS
®
assembly/repair. (p 4)
3. Ensure proper site grading for the CCT complies with state/specifying agency guidelines for
guardrail terminals or AASHTO Roadside Design Guide, whichever is more stringent. (pp 5 &
14)
4. Ensure proper site grading for CASS
®
complies with state/specifying agency guidelines or
AASHTO Roadside Design Guide. (pp 5 & 14)
5. Ensure all C-Channel posts are alternately rotated 180 degrees. (p 17)
6. Ensure the Sleeve Cover is paced on the post and is flush with the top of the Post Sleeve.
(p 21)
7. Ensure the Bottom CRP and Top CRP are oriented correctly. (pp 18 & 19 )
8. Ensure the top of the Bottom CRP’s does not protrude more than 4” [100 mm] above the
finished grade. (p 18)
9. Ensure the bent part of the Cable Anchor Bracket at CRP-1, -2, and -3 is up and hooked over
the Top CRP-1, -2, and -3. (p 22)
10. Ensure two (2) 1” Hex Nuts have been placed on the ends of the cable fittings at the CRP’s.
(p 22)
11. Ensure the cables are located and assembled at the proper holes of the Terminal Line Posts
with the Cable Lock Bolts. (p 22 & 23)
12. Ensure that the Field Applied Fittings have a single cable strand bent over the wedge. (p 24)
13. Ensure Cable Spacers are placed between the three (3) cables. (p 26)
14. Ensure the reflective spacers or markers are placed between the three (3) cables per the
contract plans. (p 26)
15. Ensure the Stainless Steel Post Strap is placed above the middle cable. (p 26)
16. Ensure the Fittings are a minimum of 1-1/2” [38 mm], maximum of 4” [100 mm] into the
turnbuckle. (p 28)
17. Ensure the Tension on the cable has been checked and is as specified in “CASS® C-
Channel Temperature/Tension Chart”. (p 28)
18. Ensure there are no damaged/frayed/bent cables. (p 29)
19. Ensure delineation is placed on CASS
®
CRP’s and line post per MUTCD and/or
state/specifying agency. (p 29)
