TRIOMED UNIVERSAL. USER MANUAL
17
Theradiatorincludes(Fig4):
• LEDtoindicatethefunctioningofthedevice;
• miniUSB5pinconnectorforthecable(USBA–miniUSB
B 5pin);
• MMEMRgeneratororIR-diode(dependingofthe
radiator type)
Light indicator
Identication
number
Factory number
miniUSB B 5pin
connector
Figure 4.
Externalradiator.Topview Working surface
The device with the batteries in is always on standby.
Figure5
Figure 6
